Tool shank type |
BT30 |
|
X Axis travel |
400mm |
|
Y Axis travel |
400mm+180mm（ATC stroke） |
|
Z Axis travel |
300mm（90mm ATC stroke included） |
|
Rapid feed rate (X,Y,Z) |
50/50/50m/min |
|
Table working surface |
650mm*400mm |
|
Maximum loading weight |
350kg |
|
Maximum spindle speeds |
12,000min-1 |
|
Spindle motor |
5.5/3.7kw |
|
Magazine tool capacity |
21 tools |
|
E-LOARDER Weight Capacity |
15kg |
|
E-LOARDER Loading time |
7 sec |
|
Floor space (W x L) |
1,990*2,550mm |
